3D Exercise 300

Exercise 300

Features used to make this exercise:

In this CAD tutorial we'll use the features:

1. Sketch: Creates a 2D sketch for modeling.

2. Extrude: Extends a 2D sketch into a 3D shape by adding or removing material.

3. Mirror: Duplicates and reflects a feature or body across a plane.

4. Thread: Generates external or internal threads on cylinders.

5. Revolve: Rotates a 2D profile around an axis to create a 3D solid.

6. Insert Fastener: Adds standard hardware components (e.g., screws, bolts, nuts) from the Fusion 360 library into the assembly.

7. Fillet: Rounds off edges or corners of a model. Chamfer: Creates a beveled edge between two faces or edges.

All dimensions are in mm/g/s/ISO

#Fusion360 #Solidworks #Inventor #Autocad #FreeCAD

2D Sketch

Sketch 300

Tip: Subscribe to the channel for more tutorials like this.

Tutorial In Autodesk Fusion: https://youtu.be/SySFXfxw1FY
